Arnott SK-5639 Rear Right Shock Land Rover Range Rover Velar (L560) w/Adaptive Air & Coil

SK-5639 is an Arnott designed new rear shock for the 2018-2020 Land Rover Velar (L560 Chassis) with CVD. This premium mono tube shock, which fits the REAR RIGHT, includes a custom tuned and thoroughly road-tested damper which provides a smooth ride and excellent performance. Included in the Arnott design are new top and bottom mounts, polyurethane bump stop, and a protective dust cover. This aftermarket rear shock is designed, tested and assembled in the USA.

FEATURES

• Adaptive to Passive
• Exclusively for the Land Rover Velar (L560) with CVD
• Fits REAR RT
• Custom Tuned Damper
• Designed & Assembled in the USA
• Premium Shock

SPECIFICATIONS

• Adjustable Damping: No
• Adjustable Ride Height: No
• Air Ride Suspension: YES
• Bearing Plate Included: NO
• Boot Included: No
• Compressed Length: 522
• Extended Length: 667
• Gas Charged: YES
• Grade Type: Standard
• Internal Construction Type: Monotube
• Internal Damper Type: Hydraulic
• Lower Mount Type: Loop Bushing
• Lower Mounting Isolator Included: YES
• Mounting Hardware Included: YES
• New Or Remanufactured: New
• Shock Spring Assisted: NO
• Springs Included: NO
• Travel Length: 145
• Upper Mount Type: Special
• Upper Mounting Isolator Included: NO

Replaces OEM part Numbers: LR106829, LR109360, LR123528, LR147263, LR090656, LR090655, LR108022, LR147262
