Bilstein 27-339022 AS3 Series Shock

Bilstein AS3 Series shock absorbers are developed to deliver superior damping characteristics with virtually no rod pressure build-up. Based on Bilsteins race-proven 46mm monotube design, the AS3s unique piggyback nitrogen chamber delivers a fade-free performance without the gas pressure buildup thats common in conventional shock designs. The aluminum threaded body modular assembly with single adjustable shaft tuning is purchased as a dry kit with pistons, piston bands and heims sold separately. The AS3 Series shock absorber offers consistent grip and optimal traction.

Specifications

• Adjustable Damping: Single Adjustable - Rebound
• Body Design: Threaded Body Screw Top (Coilover)
• Body Diameter (ID): 46mm
• Body Material: Aluminum
• Collapsed Length (IN): 17.58
• Collapsed Length (MM): 446.5
• Extended Length (IN): 22.83
• Extended Length (MM): 580
• Finish: Clear Anodized
• Internal Design: Monotube
• Lower Mount Type: 1/2in Heim
• Piston Type: Sold Separately
• Prop 65 - Short Label: WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
• Spring Hardware: E4-MSG-0096A00
• Spring Seat Included: Yes
• Upper Mount Type: 1/2in Heim
• Valving Identifier: Dry Kit (no valving)
