ICON K73003 Stage 3 Suspension System Small Taper GM 1500 1-3" Lift

2007-2016 GM 1500 1-3" LIFT STAGE 3 SUSPENSION SYSTEM (SMALL TAPER)

• Fits 2WD and 4WD models
• Increased wheel travel and ride quality over stock with no change in towing capacity
• Vehicle specific tuned front and rear shocks for superior shock damping and control
• Adjustable coilovers from 1-3" of lift height
• 6061 Aircraft grade aluminum CNC machined components
• Corrosion resistant CAD plated coilover shock bodies with 7/8 shafts
• High strength alloy CNC machined lower bar pin
• FK rod end bearings for extended longevity and minimal deflection
• 2.5 Aluminum Series rear shocks feature one-piece impact extruded aluminum cylinders for excellent corrosion resistance and consistent finish
• 100% Bolt-on system - no drilling, cutting, or welding necessary for install

• OEM Wheels & Tires Fitment: Yes
• APPLICATION NOTE #48: SLIGHT MODIFICATIONS TO FACTORY SHOCK MOUNTS MAY BE REQUIRED
• APPLICATION NOTE #55: SHOCKS ARE FULLY SERVICEABLE. COILOVER HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE
• APPLICATION NOTE #89: DOES NOT WORK ON SUV MODELS
• TECH NOTE: Only compatible with OE spindles. DO NOT install in combination with ANY aftermarket spindles.
• TECH NOTE: Not compatible with models equipped Magnetic Ride Control
• TECH NOTE: Not compatible with Hybrid models
• TECH NOTE: Included rear shocks are compatible with 0-1.5" of rear lift on most models
• TECH NOTE: Small taper applications can be identified by their forged steel OE front lower control arms
• Ships in multiple boxes
